JOHNSON PUMP 2200 GPH Heavy Duty Electric Bilge Pump

Dependable bilge pumps for commercial and recreational use.

Designed to meet and exceed the tough demands of commercial and recreational duty, these pumps feature a 12-pole motor with double ball bearings for extended service life. Impellers are carefully designed to maximize head and flow. 2200 and 4000 GPH models incorporate a mechanical seal design that eliminates shaft wear. All models feature snap-in bases that can be easily removed to clear debris. Outlet port check valve included for optional use.

Key Features

• Double ball-bearing motors for extended service life
• Snap-in base allows easy removal for clearing of debris
• Outlet port check valve included for optional use

Specifications

• Type: Submersible centrifugal electric bilge pump
• Port Sizes: 1-1/8″–2″
• Built-In Switch: No
• Material: Thermoplastic body, stainless-steel shaft
• Warranty: Three years

Capacity	Amperage	Port Dia.	Dimensions
1600gph	7A @ 12V DC	1 1/8″ & 1 1/4″	5 7/8″H x 4 1/4″dia.
2200gph	7.5A @ 12V DC	1 1/8″ & 1 1/4″	7″H x 4 1/4″dia.
4000gph	19.5A @ 12V DC	1 1/2″ & 2″	8 1/2″H x 4 13/16″dia.

More Information

For installation instructions, see the Heavy-Duty Bilge Pump Data Sheet.
